Building a Regression MLP Using the Sequential API

Let’s switch to the California housing problem and tackle it using a regression neural network. For simplicity, we will use Scikit-Learn’s fetch_california_housing() function to load the data. This dataset is simpler since it contains only numerical features. There is no ocean_proximity feature, and there is no missing value. After loading the data, we split it into a training set, a validation set and a test set, and we scale all the features:

from sklearn.datasets import fetch_california_housing
from sklearn.model_selection import train_test_split
from sklearn.preprocessing import StandardScaler
housing = fetch_california_housing()
X_train_full, X_test, y_train_full, y_test = train_test_split(
 housing.data, housing.target)
X_train, X_valid, y_train, y_valid = train_test_split(
 X_train_full, y_train_full)
scaler = StandardScaler()
X_train_scaled = scaler.fit_transform(X_train)
X_valid_scaled = scaler.transform(X_valid)
X_test_scaled = scaler.transform(X_test)

We build, train, evaluate, and use a regression MLP using the Sequential API. Making predictions is quite similar to what we did for classification. We build, train, and evaluate the regression MLP. Using the Sequential API, we make predictions that follow a process similar to our work on classification. The main differences are the fact that the output layer has a single neuron. This is because we only want to predict a single value. The output layer uses no activation function. The loss function is the mean squared error. Since the dataset is quite noisy, we just use a single hidden layer with fewer neurons than before, to avoid overfitting:

model = keras.models.Sequential([
 keras.layers.Dense(30, activation="relu", input_shape=X_train.shape[1:]),
 keras.layers.Dense(1)
])
model.compile(loss="mean_squared_error", optimizer="sgd")
history = model.fit(X_train, y_train, epochs=20,
 validation_data=(X_valid, y_valid))
mse_test = model.evaluate(X_test, y_test)
X_new = X_test[:3] # pretend these are new instances
y_pred = model.predict(X_new)

As you can see, the Sequential API is quite easy to use. However, sequential models are extremely common. It is sometimes useful to build neural networks with more complex topologies. Additionally, you might need models with multiple inputs or outputs. For this purpose, Keras offers the Functional API.

Building Complex Models Using the Functional API

One example of a non-sequential neural network is a Wide & Deep neural network. This neural network architecture was introduced in a 2016 paper by Heng-Tze Cheng et al.14. It connects all or part of the inputs directly to the output layer. This architecture makes it possible for the neural network to learn both deep patterns. It uses the deep path for these patterns. It can also learn simple rules through the short path. In contrast, a regular MLP forces all the data to flow through the full stack of layers. As a result, simple patterns in the data may end up being distorted by this sequence of transformations.

Let’s build such a neural network to tackle the California housing problem:

input = keras.layers.Input(shape=X_train.shape[1:])
hidden1 = keras.layers.Dense(30, activation="relu")(input)
hidden2 = keras.layers.Dense(30, activation="relu")(hidden1)
concat = keras.layers.Concatenate()[input, hidden2])
output = keras.layers.Dense(1)(concat)
model = keras.models.Model(inputs=[input], outputs=[output])

Let’s go through each line of this code:

• First, we need to create an Input object. This is needed because we may have multiple inputs, as we will see later.
• Next, we create a Dense layer with 30 neurons and using the ReLU activation function. As soon as it is created, notice that we call it like a function, passing it the input. This is why this is called the Functional API. Note that we are just telling Keras how it should connect the layers together. No actual data is being processed yet.
• We then create a second hidden layer, and again we use it as a function. Note however that we pass it the output of the first hidden layer.
• Next, we create a Concatenate() layer, and once again we immediately use it like a function, to concatenate the input and the output of the second hidden layer (you may prefer the keras.layers.concatenate() function, which creates a Concatenate layer and immediately calls it with the given inputs).
• Then we create the output layer with a single neuron and no activation function. We call it like a function, passing it the result of the concatenation.
• Lastly, we create a Keras Model, specifying which inputs and outputs to use.

Once you have built the Keras model, everything is exactly like earlier. There is no need to repeat it here. You must compile the model. Train it and evaluate it. Then, use it to make predictions. But what if you want to send a subset of the features through the wide path? What if you want a different subset, overlapping, through the deep path? In this case, one solution is to use multiple inputs. For example, suppose we want to send 5 features through the deep path (features 0 to 4), and 6 features through the wide path (features 2 to 7):

input_A = keras.layers.Input(shape=[5])
input_B = keras.layers.Input(shape=[6])
hidden1 = keras.layers.Dense(30, activation="relu")(input_B)
hidden2 = keras.layers.Dense(30, activation="relu")(hidden1)
concat = keras.layers.concatenate([input_A, hidden2])
output = keras.layers.Dense(1)(concat)
model = keras.models.Model(inputs=[input_A, input_B], outputs=[output])

The code is self-explanatory. Note that we specified inputs=[input_A, input_B]
when creating the model. Now we can compile the model as usual, but when we call the fit() method, instead of passing a single input matrix X_train, we must pass a pair of matrices (X_train_A, X_train_B): one per input. The same is true for X_valid, and also for X_test and X_new when you call evaluate() or predict():

model.compile(loss="mse", optimizer="sgd")
X_train_A, X_train_B = X_train[:, :5], X_train[:, 2:]
X_valid_A, X_valid_B = X_valid[:, :5], X_valid[:, 2:]
X_test_A, X_test_B = X_test[:, :5], X_test[:, 2:]
X_new_A, X_new_B = X_test_A[:3], X_test_B[:3]
history = model.fit((X_train_A, X_train_B), y_train, epochs=20,
 validation_data=((X_valid_A, X_valid_B), y_valid))
mse_test = model.evaluate((X_test_A, X_test_B), y_test)
y_pred = model.predict((X_new_A, X_new_B))

There are also many use cases in which you may want to have multiple outputs:

• The task may demand it, for example you may want to locate and classify the main object in a picture. This is both a regression task (finding the coordinates of the object’s center, as well as its width and height) and a classification task.
• Similarly, you may have multiple independent tasks to perform based on the same data. Sure, you could train one neural network per task, but in many cases you will get better results on all tasks by training a single neural network with one output per task. This is because the neural network can learn features in the data that are useful across tasks.
• Another use case is as a regularization technique (i.e., a training constraint whose objective is to reduce overfitting and thus improve the model’s ability to generalize). For example, you may want to add some auxiliary outputs in a neural network architecture to ensure that the underlying part of the network learns something useful on its own, without relying on the rest of the network.

Adding extra outputs is quite easy: just connect them to the appropriate layers and add them to your model’s list of outputs. For example, the following code builds the network represented in Figure above.

[...] # Same as above, up to the main output layer
output = keras.layers.Dense(1)(concat)
aux_output = keras.layers.Dense(1)(hidden2)
model = keras.models.Model(inputs=[input_A, input_B],
 outputs=[output, aux_output])

Each output will need its own loss function, so when we compile the model we should pass a list of losses (if we pass a single loss, Keras will assume that the same loss must be used for all outputs). By default, Keras will compute all these losses and simply add them up to get the final loss used for training. However, we care much more about the main output than about the auxiliary output (as it is just used for regularization), so we want to give the main output’s loss a much greater weight. Fortunately, it is possible to set all the loss weights when compiling the model:

model.compile(loss=["mse", "mse"], loss_weights=[0.9, 0.1], optimizer="sgd")

Now when we train the model, we need to provide some labels for each output. In this example, the main output and the auxiliary output should try to predict the same thing, so they should use the same labels. So instead of passing y_train, we just need to pass (y_train, y_train) (and the same goes for y_valid and y_test):

history = model.fit(
 [X_train_A, X_train_B], [y_train, y_train], epochs=20,
 validation_data=([X_valid_A, X_valid_B], [y_valid, y_valid]))

When we evaluate the model, Keras will return the total loss, as well as all the individual losses:

total_loss, main_loss, aux_loss = model.evaluate(
 [X_test_A, X_test_B], [y_test, y_test])

Similarly, the predict() method will return predictions for each output:

y_pred_main, y_pred_aux = model.predict([X_new_A, X_new_B])

As you can see, you can build any sort of architecture you want quite easily with the Functional API. Let’s look at one last way you can build Keras models.
